Product Details
- Size: 200CBM
- Place of Origin: China
- Brand Name: DAHAN
- Model Number: 3520
- Weight: 30000.000 kg
Quick Details
| Feature | Tower Crane | Condition | New | Application | construction,building,-20~ 40 degree |
| Rated Loading Capacity | 3t | Rated Lifting Moment | 360kn.m | Max. Lifting Load | 3t |
| Max. Lifting Height | 102.8m | Span | 35m | Place of Origin | Shandong, China (Mainland) |
| Brand Name | DAHAN | Model Number | 3520 | Rated load moment | 630kn.m |
| Max. rated load capacity | 3.0t | Working radius | 4-35m | Rated load capacity at max. radius | 2.0t |
| Freestanding | 35.3m | Attaching | 102.8m | Maximum Working elevation | 82.3 |
| Minimum Working elevation | 18 | Counter weight | 3.72t | Total power | 54kw |
Packaging & Delivery
| Packaging | 5*40HQ containers |
| Delivery | within 20 days |
- Size: 200CBM
- Place of Origin: China
- Brand Name: DAHAN
- Model Number: 3520
- Weight: 30000.000 kg
Parameter name | Unit | Designed value | |||
Rated load moment | kNm | 630 | |||
Max. rated load capacity | t | 3.0 | |||
Working radius | m | 4-35 | |||
Rated load capacity at max. radius | t | 2.0 | |||
Tower height | Freestanding | m | 35.3 | ||
Attaching | m | 102.8 | |||
Working elevation | Maximum | o | 82.3o | ||
Minimum | o | 18o | |||
Hoisting mechanism | Motor type | YZTD225L2-4/8/32 | |||
Pulley rate | 2 | ||||
Hoisting speed | m/min | 8.5 | 40 | 80 | |
Corresponding load capacity | t | 3.0 | 3.0 | 1.5 | |
Motor power | kW | 24 | |||
Trolley mechanism | Motor type | YTLVFE180M1-4 | |||
Trolley speed | m/min | ≤3min | |||
Motor power | KW | 18.5 | |||
