- Size: 100
- Place of Origin: China
- Brand Name: DAHAN
- Model Number: QTZ125(6015)
- Weight: 30000.000 kg
Quick Details
| Feature | Tower Crane | Condition | New | Application | All kinds of Demands |
| Rated Loading Capacity | 10T | Rated Lifting Moment | 1250KN.M | Max. Lifting Load | 10T |
| Max. Lifting Height | 200M | Span | 3-60M | Place of Origin | Shandong, China (Mainland) |
| Brand Name | DAHAN | Model Number | QTZ125(6015) | Welding Process | Panasonic Robot Systems |
| Painting Process | Impeller Blasting Systems | Certification | ISO9001:2000/Russia Certificate/Korea Certificate | Electrical Equipment | France Schneider |
Packaging & Delivery
| Packaging | Seaworthy Containers |
| Delivery | 19 Days Delivery at qingdao |
- Size: 100
- Place of Origin: China
- Brand Name: DAHAN
- Model Number: QTZ125(6015)
- Weight: 30000.000 kg
Load Diagram:
Jib (m) | Fall | R(Cmax) m | C(max) t | 20 | 25 | 30 | 35 | 40 | 45 | 50 | 55 | 60 |
60 | IV | 14.6 | 10.0 | 6.99 | 5.35 | 4.25 | 3.46 | 2.87 | 2.42 | 2.05 | 1.75 | 1.50 |
II | 26.37 | 5.0 | 5.0 | 5.00 | 4.25 | 3.46 | 2.87 | 2.42 | 2.05 | 1.75 | 1.50 | |
55 | IV | 15.3 | 10.0 | 7.41 | 5.70 | 4.52 | 3.70 | 3.08 | 2.60 | 2.21 | 1.90 | |
II | 27.70 | 5.0 | 5.0 | 5.00 | 4.52 | 3.70 | 3.08 | 2.60 | 2.21 | 1.90 | ||
50 | IV | 15.7 | 10.0 | 7.62 | 5.85 | 4.66 | 3.82 | 3.19 | 2.69 | 2.30 | ||
II | 28.38 | 5.0 | 5.0 | 5.00 | 4.66 | 3.82 | 3.19 | 2.69 | 2.30 | |||
45 | IV | 16.5 | 10.0 | 8.08 | 6.23 | 4.97 | 4.09 | 3.42 | 2.90 | |||
II | 29.87 | 5.0 | 5.0 | 5.00 | 4.97 | 4.09 | 3.42 | 2.90 | ||||
40 | IV | 17.2 | 10.0 | 8.45 | 6.52 | 5.22 | 4.30 | 3.60 | ||||
II | 31.03 | 5.0 | 5.0 | 5.00 | 5.0 | 4.30 | 3.60 |
