- Size: 150CBM
- Place of Origin: China
- Brand Name: DAHAN
- Model Number: QTZ100(6013)
- Weight: 30000.000 kg
Quick Details
| Feature | Tower Crane | Condition | New | Application | Construction |
| Rated Loading Capacity | 1.3T | Rated Lifting Moment | 1000KN.m | Max. Lifting Load | 6T |
| Max. Lifting Height | 200m | Span | 60M | Place of Origin | Shandong, China (Mainland) |
| Brand Name | DAHAN | Model Number | QTZ100(6013) | Certification | CE ISO SGS |
| Warranty | 12 Months | After-sales Service Provided | Engineers available to service machinery overseas | Mast Section Size | 1.6*1.6*2.8m |
| Main Chord | 135*135*12 | Free Standing Height | 40M | Max. Height | 200m |
| Total Power | 34.7kw | Type | Topkit Tower Crane | Item Name | QTZ100(6013) DAHAN Crane Tower With Good Price |
| Foundation | Embedded Foundation Leg | Trolleying Speed | 44m/min | Slewing Speed | 0.6r/min |
Packaging & Delivery
| Packaging | Container for QTZ100(6013) DAHAN Crane Tower With Good Price |
| Delivery | Shipped in 5 days after payment |
- Size: 150CBM
- Place of Origin: China
- Brand Name: DAHAN
- Model Number: QTZ100(6013)
- Weight: 30000.000 kg
QTZ100(6013) parameter table
Name
|
Unit |
Parameter | ||
Rated Load moment | KN·m | 1000 | ||
MAX hoisting capacity | t | 6 | ||
Rated hoisting capacity max radius
| t | 1.6 | ||
Working radius
| m | 3---55 | ||
height |
Freestanding
| m | a=2,45 | |
a=4,45 | ||||
attaching | m | a=2,220 | ||
a=4,110 | ||||
hoisting speed |
Double rate | a=2 | a=4 | |
lifting speed | m/min | 80/40/10 | 40/20/5 | |
Slewing speed | r/min | 0.62 | ||
trolleying speed | m/min | 48/24 | ||
The max. slewing radius | m | 40 | ||
Tail slewing radius | m | 10
| ||
Temperature of working environment | -20∼ 40 | |||
