- Size: 150CBM
- Place of Origin: China
- Brand Name: DAHAN
- Model Number: QTZ63 (5013)
- Weight: 30000.000 kg
Quick Details
| Feature | Tower Crane | Condition | New | Application | Construction |
| Rated Loading Capacity | 6.0T | Rated Lifting Moment | 630KN.m | Max. Lifting Load | 6.0T |
| Max. Lifting Height | 120m | Span | 3m~50m | Place of Origin | Shandong, China (Mainland) |
| Brand Name | DAHAN | Model Number | QTZ63(5013) | Type | QTZ63(5013) |
| Basic height | 40m | Max.hoisting height | 120m | Jib length | 50m |
| Mast section dimension | single angle steel1.6*1.6*2.5 or square tube steel1.6*1.6*2.8 | Mast section chord | single angle 160*160*12 or square tube steel 135*135*12 | Number of mast section | single angle 15 or square tube 13 |
| Cutting technology | 6m*12m CNC plasma cutting machine | Certification | ISO9001:2008,CE, GOST,Korea certificate |
Packaging & Delivery
| Packaging | Seaworthy packing (It need 40 HQ for six of basic height) |
| Delivery | Around 15 days after receiving your adavanced payment by 30% |
- Size: 150CBM
- Place of Origin: China
- Brand Name: DAHAN
- Model Number: QTZ63 (5013)
- Weight: 30000.000 kg
Rated load moment | kN•m | 630 | |||||||
Max. load capacity | t | 6.0 | |||||||
Rated radius | m | 3~50 | |||||||
Rated load capacity at max.radius | t | 1.3 | |||||||
Hoisting height | Freestanding | m | 40 | ||||||
Attaching | Double rate | m | 120 | ||||||
Quadruple rate | m | 60 | |||||||
Hoisting mechanism | Hoisting speed | Rate | / | a=2 | a=4 | ||||
Speed | m/min | 8.5 | 40 | 80 | 4.25 | 20 | 40 | ||
Max.load capacity | t | 3 | 3 | 1.5 | 6 | 6 | 3 | ||
Motor type | / | YZTD225L2-4/8/32 | |||||||
Power | kw | 24/24/5.4 | |||||||
Speed | r/min | 1400/720/165 | |||||||
Slewing mechanism | Slewing speed | r/min | 0.6 | ||||||
Motor type | / | YZR132M2-6 | |||||||
Power | kw | 3.7×2 | |||||||
Speed | r/min | 908 | |||||||
Trolley mechanism | Trolley speed | m/min | 48/24 | ||||||
Motor type | / | YDEJ132S-4/8 | |||||||
Power | kw | 3.3/2.2 | |||||||
Speed | r/min | 1400/720 | |||||||
Climbing mechanism | Climbing speed | m/min | 0.50 | ||||||
Hydraulic system rated working pressure | Mpa | 25 | |||||||
Motor type | / | Y132M-4 | |||||||
Power | kw | 7.5 | |||||||
Speed | r/min | 1440 | |||||||
Tail slewing radius | m | 12.8 | |||||||
Counter weight | t | 12 | |||||||
Total power(not include climbing system) | kW | 30.6 | |||||||
Allowed working temperature | °C | -20~ 40 | |||||||
Power supply parameter | 50Hz | ~380V±5% | |||||||
Table 1 Double rate
Range( m) | 24 | 26 | 28 | 30 | 32 | 34 | 36 | 38 | 40 |
Hoisting load capacity (t) | 3 | 2..86 | 2.63 | 2.43 | 2.25 | 2.10 | 1.96 | 1.83 | 1.72 |
Range (m) | 42 | 44 | 46 | 48 | 50 | ||||
Hoisting load capacity( t) | 1.62 | 1.53 | 1.45 | 1.37 | 1.3 |
Table 2 Quadruple rate
Range (m) | 13.22 | 14 | 16 | 18 | 20 | 22 | 24 | 26 | 28 |
Hoisting load capacity (t) | 6 | 5.64 | 4.89 | 4.3 | 3.83 | 3.45 | 3.13 | 2.86 | 2.63 |
Range (m) | 30 | 32 | 34 | 36 | 38 | 40 | 42 | 44 | 46 |
Hoisting load capacity(t) | 2.43 | 2.25 | 2.1 | 1.96 | 1.83 | 1.72 | 1.62 | 1.53 | 1.45 |
Range( m) | 48 | 50 | |||||||
Hoisting load capacity (t) | 1.37 | 1.3 |
