- Size: 150CBM
- Place of Origin: China
- Brand Name: DAHAN
- Model Number: QTZ80(5613)
- Weight: 30000.000 kg
Quick Details
| Feature | Tower Crane | Condition | New | Application | All kinds of demand |
| Rated Loading Capacity | 6T/8T | Rated Lifting Moment | 800kn.m | Max. Lifting Load | 6t/8t |
| Max. Lifting Height | 200m | Span | 3-60m | Place of Origin | Shandong, China (Mainland) |
| Brand Name | DAHAN tower crane | Model Number | TC5613/6010 | Mast section | 1.8*1.8*2.8m |
| Main steel | 135*135*12 Q345B | Freestanding height | 40m | Max. height | 150m |
| Color | Obtional | Voltage,frequency | 380v/50hz,can changeable |
Packaging & Delivery
| Packaging Details | Seaworthy packing (6*40HQ containers) |
| Delivery Detail | About 10 days delivery at qingdao port |
- Size: 150CBM
- Place of Origin: China
- Brand Name: DAHAN
- Model Number: QTZ80(5613)
- Weight: 30000.000 kg
QTZ80 Mechanisms
parameters | units | QTZ80(5613) | QTZ80(6010) | ||
Rated load moment | KN.m | 800 | 800 | ||
Max load | t | 6/8 | 6/8 | ||
Max working radius | m | 56 | 60 | ||
Max height | freestanding | m | 45 | 45 | |
attaching | 150 | 150 | |||
hoisting speed | a=2 | m/min | 8/40/80 | 8/40/80 | |
b=2 | 4/20/40 | 4/20/40 | |||
Tip capacity | t | 1.3 | 1.0 | ||
Trolleying speed | m/min | 21/42 | 21/42 | ||
Swing speed | r/min | 0.62 | 0.62 | ||
Climbing speed | m/min | 0.4 | 0.4 | ||
Crane weight | t | 42.5 | 43.0 | ||
Total power | KW | 36.4 | 36.4 | ||
Working voltage | V | ~380V±50%HZ | |||
Max working pressure | N/ | 250 | |||
Load diagram
Jib (m) | Fall | R(Cmax) (m) | C(max) (t) | 12 | 16 | 20 | 24 | 28 | 32 | 36 | 40 | 44 | 48 | 52 | 56 | 60 |
60 | IV | 12.0 | 8.0 | 8.0 | 5.71 | 4.39 | 3.52 | 2.91 | 2.45 | 2.1 | 1.82 | 1.6 | 1.41 | 1.25 | 1.11 | 1.0 |
II | 21.6 | 4.0 | 4.0 | 4.0 | 4.0 | 3.52 | 2.91 | 2.45 | 2.1 | 1.82 | 1.6 | 1.41 | 1.25 | 1.11 | 1.0 | |
56 | IV | 13.16 | 8.0 | 8.0 | 6.38 | 4.92 | 3.96 | 3.28 | 2.78 | 2.39 | 2.09 | 1.83 | 1.63 | 1.46 | 1.30 | |
II | 23.8 | 4.0 | 4.0 | 4.0 | 4.0 | 3.96 | 3.28 | 2.78 | 2.39 | 2.09 | 1.83 | 1.63 | 1.46 | 1.30 |
