- Size: 100CBM
- Place of Origin: JiNan China
- Brand Name: DAHAN
- Model Number: QTZ100(5516)
- Weight: 30000.000 kg
Quick Details
| Feature | Tower Crane | Condition | New | Application | Construction,Bridge,Wharf etc |
| Rated Loading Capacity | 6T | Rated Lifting Moment | 1000KN.M | Max. Lifting Load | 6T |
| Max. Lifting Height | 150M | Span | 3-55M | Place of Origin | Shandong, China (Mainland) |
| Brand Name | Dahan | Model Number | QTZ100 (5516) | Jib length | 55m |
| Freestanding height | 45m | tip load | 1.6t | Dimension of mast | 1.6*1.6*3.0 square tube |
| specification of main chord | 180*180*18 | Material | Q345B manganese steel | Voltage & frequency | 380v/50hz,380v/60hz,400v/50hz,440v/60hz |
| Electrical Equipment | Schneider Brand | colour | orange | temperature | -20~ 40 |
Packaging & Delivery
| Packaging | 6*40HP |
| Delivery | 1~15 Days after Payment |
- Size: 100CBM
- Place of Origin: JiNan China
- Brand Name: DAHAN
- Model Number: QTZ100(5516)
- Weight: 30000.000 kg
Specifications
Tower crane technical parameters table | ||||||||||||||||
Name | Unit | Designed value | ||||||||||||||
Rated load moment | kN.m | 1000 | ||||||||||||||
Max.rated load capacity | t | 6.0 | ||||||||||||||
Hoisting height | Freestanding type | m | 45 | |||||||||||||
Attaching type | Double rate | m | 150 | |||||||||||||
Quadruple rate | m | 75 | ||||||||||||||
Hoisting mechanism | Hoisting speed | Rate | / | α=2 | α=4 | |||||||||||
Speed | m/min | 10 | 40 | 80 | 5 | 20 | 40 | |||||||||
Conresponding max.load capacity | t | 4 | 4 | 2 | 8 | 8 | 4 | |||||||||
Motor type | / | YZRDW250M-4/8 | ||||||||||||||
Power | kW | 30/30 | ||||||||||||||
Speed | r/min | 1420/725 | ||||||||||||||
Slewing mechanism | Slewing speed | r/min | 0.62 | |||||||||||||
Motor type | / | YZR132M2-6 | ||||||||||||||
Power | kW | 3.7×2 | ||||||||||||||
Speed | r/min | 908 | ||||||||||||||
Derricking mechanism | Derricking speed | m/min | 48/24 | |||||||||||||
Motor type | / | YDEJ132S-4/8B5 | ||||||||||||||
Power | kW | 3.3/2.2 | ||||||||||||||
Speed | r/min | 1450/720 | ||||||||||||||
Climbing mechanism | Climbing speed | m/min | 0.4 | |||||||||||||
Hydraulic rated working pressure | MPa | 25 | ||||||||||||||
Motor type | / | Y132M-4 | ||||||||||||||
Power | kW | 7.5 | ||||||||||||||
Speed | r/min | 1420 | ||||||||||||||
