- Size: 100CBM
- Place of Origin: JiNan China
- Brand Name: DAHAN
- Model Number: QTZ100(6013)
- Weight: 30000.000 kg
Quick Details
| Feature | Tower Crane | Condition | New | Application | Building,Construction ,Structure |
| Rated Loading Capacity | 6t | Rated Lifting Moment | 100KN.m | Max. Lifting Load | 6t |
| Max. Lifting Height | 200m | Span | 60m | Place of Origin | Shandong, China (Mainland) |
| Brand Name | Dahan | Model Number | QTZ100(6013) | Certification | ISO |
| Warranty | 1 year | Jib length | 60m | Mast Section | 1.8*1.8*2.8 |
| Main Chord | 135*135*12 | Main Chord Materials | Q345B | Normal Height | 45m |
| Tip load | 1.3t | Working Temperature | -20- 40 | Voltage | 380v/50hz,380v/60hz, 400v/50hz,440v/60hz... |
| Colour | Yellow/Red/Blue | Slewing Power | 3.7*2 |
Packaging & Delivery
| Packaging | 40HP |
| Delivery | 1~15 Days after Payment |
- Size: 100CBM
- Place of Origin: JiNan China
- Brand Name: DAHAN
- Model Number: QTZ100(6013)
- Weight: 30000.000 kg
Specifications
Hoisting Winch |
Hoisting Speed | Rate | / | α=2 | α=4
| |||||||
Speed | m/min | 8.5 | 40 | 80 | 4.25 | 20 | 40
| |||||
Correspondent Max.load Capacity | t | 3 | 3 | 1.5 | 6 | 6 | 3
| |||||
Motor Type | / | YZTD225L2-4/8/32
| ||||||||||
Power | kW | 24/24/5.4
| ||||||||||
Slewing Winch | Slewing Speed | r/min | 0.6 | |||||||||
Motor Type | / | YZR132M2-6 | ||||||||||
Power | kW | 3.7×2 | ||||||||||
Derricking Winch | Derricking Speed | m/min | 44/22 | |||||||||
Motor Type | / | YDEJ132S-4/8 | ||||||||||
Power | kW | 3.3/2.2 | ||||||||||
Climbing Winch
| Climbing Speed | m/min | 0.55 | |||||||||
Rated Working Pressure of Hydraulic System | MPa | 25 | ||||||||||
Motor Type | / | Y132M-4 | ||||||||||
Power | kW | 5.5
| ||||||||||
