Product Details
- Size: 100
- Place of Origin: China
- Brand Name: DAHAN
- Model Number: QTZ50(5008)
- Weight: 30000.000 kg
Quick Details
| Feature | Tower Crane | Condition | New | Application | construction,building, structure |
| Rated Loading Capacity | 4t | Rated Lifting Moment | 500kn.m | Max. Lifting Load | 4t |
| Max. Lifting Height | 120m | Span | 50m | Place of Origin | Shandong, China (Mainland) |
| Brand Name | Dahan | Model Number | QTZ50 (5008) | jib length | 50m |
| mast section | 1.5*1.5*2.2 | main chord | 160*160*12 | main chord materials | Q345B |
| free-stranding height | 29m | Load Capacity at Jib end | 0.8t | color | yellow/red/blue |
| Voltage/frequency | 380v/50hz,380v/60hz, 400v/60hz,440v/50hz | Working temperature | -20~ 40 | Climbing power | 3KW |
Packaging & Delivery
| Packaging | 4*40HQ |
| Delivery | 10 days after confirming order |
- Size: 100
- Place of Origin: China
- Brand Name: DAHAN
- Model Number: QTZ50(5008)
- Weight: 30000.000 kg
specifications
name
|
unit |
parameter | ||
Rated Load moment | KN·m | 500 | ||
MAX hoisting capacity | t | 4 | ||
Rated hoisting capacity max radius
| t | 0.8 | ||
Working radius
| m | 50 | ||
height |
Freestanding
| m | 29 | |
attaching | m | 140 | ||
hoisting speed |
Double rate | a=2 | a=4 | |
lifting speed | m/min | 9/30/70 | 4.5/17.5/35 | |
Slewing speed | r/min | 0.6 | ||
derricking speed | m/min | 25/38 | ||
The max. slewing radius | m | 49 | ||
Tail slewing radius | m | 13
| ||
Temperature of working environment | -20 40 | |||
