- Size: 100
- Place of Origin: China
- Brand Name: DAHAN
- Model Number: QTZ63(5211)
- Weight: 30000.000 kg
Quick Details
Feature | Tower Crane | Condition | New | Application | Construction |
Rated Loading Capacity | 1.1T | Rated Lifting Moment | 630KN.m | Max. Lifting Load | 6T |
Max. Lifting Height | 150m | Span | 52M | Place of Origin | Shandong, China (Mainland) |
Brand Name | DAHAN | Model Number | QTZ63(5211) | Certification | CE ISO SGS |
Warranty | 12 Months | After-sales Service Provided | Engineers available to service machinery overseas | Mast Section Size | 1.6*1.6*2.5m |
Main Chord | 1.6*1.6*14 | Free Standing Height | 40M | Max. Height | 150m |
Total Power | 34.7kw | Type | Topkit Tower Crane | Color | Customer Required |
Foundation | Embedded Foundation Leg | Trolleying Speed | 44m/min | Slewing Speed | 0.6r/min |
Packaging & Delivery
Packaging | Container |
Delivery | 1-3 Days after Deposit |
- Size: 100
- Place of Origin: China
- Brand Name: DAHAN
- Model Number: QTZ63(5211)
- Weight: 30000.000 kg
specifications
Hoisting | Fall | / | α=2 | β=4 | ||||
Speed | m/min | 8.5 | 40 | 80 | 4.25 | 20 | 40 | |
Load Capacity Weight | t | 3.0 | 3.0 | 1.5 | 6.0 | 6.0 | 3.0 | |
power | KW | 24/24/5.4 | ||||||
Trolleying | Speed | m/min | 44/22 | |||||
Power | N.m | 3.3/2.2 | ||||||
Slewing | Speed | r/min | 0.6 | |||||
Power | N.m | 3.7X2 | ||||||
Jacking | Speed | m/min | 0.55 | |||||
Operating Pressure | MPa | 25 | ||||||
Power | KW | 5.5 | ||||||
Total Power | KW | 34.7 |
