Product Details
- Size: 100
- Place of Origin: China
- Brand Name: DAHAN
- Model Number: D5020
- Weight: 30000.000 kg
Quick Details
| Feature | Tower Crane | Condition | New | Application | Construction |
| Rated Loading Capacity | 2T | Rated Lifting Moment | 3688KN.m | Max. Lifting Load | 10T |
| Max. Lifting Height | 199m | Span | 50M | Place of Origin | Shandong, China (Mainland) |
| Brand Name | DAHAN | Model Number | D5020 | Certification | CE ISO SGS |
| Warranty | 12 Months | After-sales Service Provided | Engineers Available to Service Machinery Overseas | Mast Section Size | 2*2*3m |
| Main Chord | 200*200*20 | Free Standing Height3 | 37.65M | Max. Height | 199m |
| Total Power | 101kw | Type | Luffing Jib Tower Crane | Color | Customer Required |
| Slewing Speed | 0-0.62r/min | Max. Elevation | 84 | Min. Elevation | 15 |
Packaging & Delivery
| Packaging | Luffing Jib Tower Crane accept in Containers |
| Delivery | 1-15 days after deposit |
- Size: 100
- Place of Origin: China
- Brand Name: DAHAN
- Model Number: D5020
- Weight: 30000.000 kg
specifications
| Hoisting | Fall | / | α=2 | α=4 | ||
| Speed | m/min | 0~40 | 0~80 | 0~20 | 0~40 | |
| Load Capacity Weight | t | 5.0 | 2.5 | 10 | 5.0 | |
| power | KW | 45 | ||||
| Trolleying | Speed | m/min | 0~45 | |||
| Power | N.m | 37 | ||||
| Slewing | Speed | r/min | 0~0.62 | |||
| Power | N.m | 14.5x2 | ||||
| Jacking | Speed | m/min | 0.55 | |||
| Operating Pressure | MPa | 35 | ||||
| Power | KW | 11 | ||||
| Total Power | KW | 101 | ||||
