- Size: 100
- Place of Origin: China
- Brand Name: DAHAN
- Model Number: QTZ250(7032)
- Weight: 30000.000 kg
Quick Details
| Feature | Tower Crane | Condition | New | Application | Construction |
| Rated Loading Capacity | 3.2T | Rated Lifting Moment | 2500KN.m | Max. Lifting Load | 12T |
| Max. Lifting Height | 225m | Span | 70M | Place of Origin | Shandong, China (Mainland) |
| Brand Name | DAHAN | Model Number | QTZ250(7032) | Certification | CE ISO SGS |
| Warranty | 12 Months | After-sales Service Provided | Engineers Available to Service Machinery Overseas | Mast Section Size | 2*2*3m |
| Main Chord | 200*200*20 | Free Standing Height | 52.5M | Max. Height | 225m |
| Total Power | 75.5kw | Type | Topkit Tower Crane | Item Name | QTZ250(7032) 12T Used Tower Crane |
| Foundation | Embedded Foundation Leg | Trolleying Speed | 44m/min | Slewing Speed | 0-0.7r/min |
- Size: 100
- Place of Origin: China
- Brand Name: DAHAN
- Model Number: QTZ250(7032)
- Weight: 30000.000 kg
Hoisting Technical Performance
Hoisting | Hoisting Speed | Fall | / | α=2 | α=4 | ||||
Speed | m/min | 0~45 | 0~90 | 0~22.5 | 0~45 | ||||
Corresponding Maximum Load Capacity Weight | t | 6.0 | 3.0 | 12 | 6.0 | ||||
Power | Kw | 55 | |||||||
Slewing | Slewing Speed | r/min | 0~63 | ||||||
Power | Kw | 5.5 | |||||||
Derricking | Derricking Speed | m/min | 0~0.7 | ||||||
Power | Kw | 7.5x2 | |||||||
Jacking | Jacking Speed | m/min | 0.55 | ||||||
Operating Pressure | Mpa | 35 | |||||||
| Power | KW | 11 | |||||||
Power Total | Kw | 75.5(not including jacking institution) | |||||||
