Product Details
- Size: 150CBM
- Place of Origin: China
- Brand Name: DAHAN
- Model Number: QTZ50(4810)
- Weight: 30000.000 kg
Quick Details
| Feature | Tower Crane | Condition | New | Application | Construction |
| Rated Loading Capacity | 4T | Rated Lifting Moment | 500KN.m | Max. Lifting Load | 4T |
| Max. Lifting Height | 120m | Span | 48m | Place of Origin | Shandong, China (Mainland) |
| Brand Name | Dahan | Model Number | QTZ50 (4810) | Certification | ISO CE SGS |
| Warranty | 12 Months | After-sales Service Provided | Engineers available to service machinery overseas | Tip load | 1.0T |
| Freestanding height | 29m | Main chord steel | 160*160*12 angle iron | Steel material | Q345B |
| Mast section specification | 1.5m*1.5m*2.2m | Volatage and frequency | 380V,50Hz(can be changed to the client's requirements) | Working temperature | -20- 40 |
| Hoisting power | 15/15/4KW | Slewing power | 3.7KW | Trolley power | 2.2/1.5KW |
Packaging & Delivery
| Packaging | 4 units(40HQ containers) for 29m height |
| Delivery | 1-3 days after deposit |
- Size: 150CBM
- Place of Origin: China
- Brand Name: DAHAN
- Model Number: QTZ50(4810)
- Weight: 30000.000 kg
Technique parameters
| QTZ50(4810) Top Kit Tower Crane | ||||||||
| Item | Unit | Details | ||||||
| Max. load | t | 4 | ||||||
| Load at jib | t | 1 | ||||||
| Jib length | m | 48 | ||||||
| Free standing/Max. height | m | 29/120 | ||||||
| Hoisting Mech. | Rate | / | 2 fall | 4 fall | ||||
| Speed | m/min | 10.8 | 35 | 71 | 5.4 | 17.5 | 35 | |
| Load capacity | T | 2 | 2 | 0.8 | 4 | 4 | 2 | |
| Power | kw | 15/15/4 | ||||||
| Trolley Mech. | Speed | m/min | 40/20 | |||||
| Power | kw | 2.4/1.5 | ||||||
| Slewing Mech. | Speed | r/min | 0.6 | |||||
| Power | kw | 3.7 | ||||||
| Jaking Mech. | Speed | m/min | 0.4 | |||||
| Operating pressure | Mpa | 20 | ||||||
| Power | kw | 4 | ||||||
| Mast section size | m | 1.5*1.5*2.2 | ||||||
| Main chord | Angle steel 160*160*12 Q345B Mn Steel | |||||||
| Working voltage | v | 380V,50HZ or meet clients requirement | ||||||
| Working temperature | ℃ | -20-40 | ||||||
