Product Details
- Place of Origin: Shandong, China (Mainland)
- Brand Name: DAHAN
- Model Number: QTZ(PT6013)
DAHAN QTZ100(PT6013) series flat top tower cranes can be used in a tower group in your construction site. This material handling equipment can carry 16T heavy load from one place to another without beyond the largest jib length of 60m. Thanks to the rated lifting moment of 100t/m, free standing height of 45m and maximum hook height realized by using wall anchoring devices, this hoisting equipment can meet the requirement of various construction projects.
- Place of Origin: Shandong, China (Mainland)
- Brand Name: DAHAN
- Model Number: QTZ(PT6013)
Main Parameters
| Model | QTZ(PT6013) | ||||||||
| Basic System | Max Load | T | 8 | ||||||
| Tip Load | T | 1.3 | |||||||
| Jib Length | M | 60 | |||||||
| Free height | M | 45 | |||||||
| Mast Section | M | 1.6x3.0 | |||||||
| Main Materials | □135x12 Q345B | ||||||||
| Hoisting | hoisting speed | Fall | / | α=2 | α=4 | ||||
| Speed | m/min | 8.5 | 40 | 80 | 4.25 | 20 | 40 | ||
| Load Capacity Weight | t | 3 | 4 | 2 | 6 | 8 | 4 | ||
| Power | Kw | 30/30 | |||||||
| Slewing | Slewing Speed | r/min | 0~0.6 | ||||||
| Power | kw | 3.7x2 | |||||||
| Derricking | Derricking Speed | m/min | 40/20 | ||||||
| Power | Kw | 3.3/2.2 | |||||||
| Jacking | Jacking Speed | m/min | 0.5 | ||||||
| Power | Kw | 7.5 | |||||||
| Power Total | Kw | 36.7 | |||||||
