Product Details
- Place of Origin: Shandong China(mainland)
- Brand Name: DAHAN
- Model Number: QTZ50(4810)
Specifications
Model Number:QTZ50 (4810)
Rated Lifting Moment:500KN.m
Max. Lifting Load:4T
Max. Lifting Height:120m
Span:48m
Certification:ISO CE SGS
Warranty:12 Months
Tip load:1.0T
Freestanding height:29m
Main chord steel:160*160*12 angle iron
Steel material:Q345B
Mast section specification:1.5m*1.5m*2.2m
Working temperature:-20- 40
Hoisting power:15/15/4KW
Slewing power:3.7KW
Trolley power:2.2/1.5KW
After-sales Service Provided:Engineers available to service machinery overseas
Volatage and frequency:380V,50Hz(can be changed to the client's requirements)
- Place of Origin: Shandong China(mainland)
- Brand Name: DAHAN
- Model Number: QTZ50(4810)
| QTZ50(4810) Top Kit Tower Crane | ||||||||
| Item | Unit | Details | ||||||
| Max. load | t | 4 | ||||||
| Load at jib | t | 1 | ||||||
| Jib length | m | 48 | ||||||
| Free standing/Max. height | m | 29/120 | ||||||
| Hoisting Mech. | Rate | / | 2 fall | 4 fall | ||||
| Speed | m/min | 10.8 | 35 | 71 | 5.4 | 17.5 | 35 | |
| Load capacity | T | 2 | 2 | 0.8 | 4 | 4 | 2 | |
| Power | kw | 15/15/4 | ||||||
| Trolley Mech. | Speed | m/min | 40/20 | |||||
| Power | kw | 2.4/1.5 | ||||||
| Slewing Mech. | Speed | r/min | 0.6 | |||||
| Power | kw | 3.7 | ||||||
| Jaking Mech. | Speed | m/min | 0.4 | |||||
| Operating pressure | Mpa | 20 | ||||||
| Power | kw | 4 | ||||||
| Mast section size | m | 1.5*1.5*2.2 | ||||||
| Main chord | Angle steel 160*160*12 Q345B Mn Steel | |||||||
| Working voltage | v | 380V,50HZ or meet clients requirement | ||||||
| Working temperature | ℃ | -20-40 | ||||||
