Product Details
- Size: 150CBM
- Place of Origin: China
- Brand Name: DAHAN
- Model Number: QTZ63(5010)
- Weight: 30000.000 kg
Quick Details
| Feature | Tower Crane | Condition | New | Application | Construction |
| Rated Loading Capacity | 4T | Rated Lifting Moment | 630KN.m | Max. Lifting Load | 4T |
| Max. Lifting Height | 120m | Span | 50M | Place of Origin | Shandong, China (Mainland) |
| Brand Name | DAHAN | Model Number | QTZ63 (5010) | Certification | CE ISO SGS |
| Warranty | 12 Months | After-sales Service Provided | Engineers available to service machinery overseas | Mast Section Size | 1.6*1.6*2.5M |
| Main Chord | 160*160*14 | Free Standing Height | 40M | Max. Height | 120m |
| Total Power | 22.9kw | Type | Topkit Tower Crane | Color | Obtional |
| Foundation | Embedded Foundation Leg | Slewing Speed | 0.6 r/min | Jacking Speed | 0.55m/min |
Packaging & Delivery
| Packaging | QTZ63(5010) 4T Tower Crane With ISO and CE Certificate And Good Price In 4 containers |
| Delivery | 1-15 days after deposit |
- Size: 150CBM
- Place of Origin: China
- Brand Name: DAHAN
- Model Number: QTZ63(5010)
- Weight: 30000.000 kg
Technique parameters:
| QTZ63(5010) Top Kit Tower Crane | ||||||||
| Item | Unit | Details | ||||||
| Max. load | t | 4 | ||||||
| Load at jib | t | 1 | ||||||
| Jib length | m | 50 | ||||||
| Free standing/Max. height | m | 40/120 | ||||||
| Hoisting Mech. | Rate | / | 2 fall | 4 fall | ||||
| Speed | m/min | 6 | 32 | 65 | 3 | 16 | 32 | |
| Load capacity | T | 2 | 2 | 0.8 | 4 | 4 | 2 | |
| Power | kw | 15/15/4 | ||||||
| Trolley Mech. | Speed | m/min | 40/20 | |||||
| Power | kw | 2.4/1.5 | ||||||
| Slewing Mech. | Speed | r/min | 0.6 | |||||
| Power | kw | 5.5 | ||||||
| Jaking Mech. | Speed | m/min | 0.55 | |||||
| Operating pressure | Mpa | 25 | ||||||
| Power | kw | 5.5 | ||||||
| Mast section size | m | 1.5*1.5*2.5/1.6*1.6*2.5 | ||||||
| Main chord | Angle steel 160*160*12/14 Q345B Mn Steel | |||||||
| Working voltage | v | 380V,50HZ or meet clients requirement | ||||||
| Working temperature | ℃ | -20-40 | ||||||
