Product Details
- Place of Origin: Shandong, China (Mainland)
- Brand Name: DAHAN
- Model Number: QTZ63(5013)
Products Description
1、Anchored to the building wall by high strength roads, the QTZ63(5013) series hammerhead tower crane can be erected to a height of 120m.
2、Without anchorage ,its free standing hook height is up to 40m.This characteristic makes the top slewing crane suitable for a large range of construction projects .
3、The construction tower crane can be used to handle heavy materials of 6 tons ,with the largest radius up to 50m.Contact us for more information about this hoisting crane.
- Place of Origin: Shandong, China (Mainland)
- Brand Name: DAHAN
- Model Number: QTZ63(5013)
Main Parame
| Model | QTZ63(5013) Tower crane | ||||||||
| Basic System | Max Load | T | 6 | ||||||
| Tip Load | T | 1.3 | |||||||
| Jib Length | M | 50 | |||||||
| Free Height | M | 30 | |||||||
| Mast Section | M | 1.5x2.2 | |||||||
| Main Materials | ∠160x14 Q345B | ||||||||
| Hoisting | hoisting speed | Fall | / | α=2 | α=4 | ||||
| Speed | m/min | 8.5 | 40 | 80 | 4.25 | 20 | 40 | ||
| Load Capacity Weight | t | 3 | 3 | 1.5 | 6 | 6 | 3 | ||
| Power | Kw | 24/24/5.4 | |||||||
| Slewing | slewing Speed | r/min | 0.6 | ||||||
| Power | Kw | 3.7x2 | |||||||
| Derricking | Derricking Speed | m/min | 48/24 | ||||||
| Power | Kw | 3.3/2.2 | |||||||
| Jacking | Jacking Speed | m/min | 0.5 | ||||||
| Power | Kw | 7.5 | |||||||
| Power Total | Kw | 42.2 | |||||||
